Application of Huge Capacity CLUM Roller Vertical Mill, Ultra Fine Grinding Mill for Sale
Vertical roller mill are suitable for huge capacity producing, widely used in grinding non-flammable and non-explosive materials under 9.3(the Moh's hardness), such as quartz, feldspar, calcite, talcum, barite, fluorite, iron ore, copper ore quartz, especially for slag, cement clinker, zircon sand, fly ash and carborundum, coal, etc.
Working Principle of CLUM Roller Vertical Mill, Grinding Mill for Sale
The grinding disc is driving by motor through reducer. The material falls to grinding disc from the feed opening. The materials are driven to the edge of disc by the centrifugal force and crushed into fine powders by rollers. Then, the hot air from the nozzle take the fine powder to high effiency classsifer.The qualified powder are taken by the air to the powder collector to be collected, while the unqualified powder are sent back for regrinding.
Advantages of CLUM Roller Vertical Mill, Grinding Mill for Sale
1. High grinding efficiency: save 20~30% power consumption compared with the ball mill. With the increasing of moisture content, it can save more and more electricity.
2. Strong drying capacity: dry and grind raw materials with moisture content as much as 15%.
3. Mutifunction: crushing, drying, grinding, separating and conveying.
4. Low noises and little dust: no direct contact between the grinding rollers and grinding disc, so metallic impact is avoided and its noises is 20~25 decibels lower. Totally closed negative pressure operation has employed by this vertical grinding mill, so there is no dust during the operation.
5. Low wear rate and little metallic pollution: its metal wear is only 5~10g/t.
The Technical Data of CLUM Roller Vertical Mill, Grinding Mill for Sale
Model
HRM1300M
HRM1400M
HRM1500M
HRM1700M
HRM1900M
Grinding disc diameter mm
Φ1300
Φ1400
Φ1500
Φ1700
Φ1900
Output T/H
10-15
12-17
16-22
20-28
26-35
Feeding size mm
0-40
0-40
0-45
0-50
0-55
Feeding moisture %
<15
<15
<15
<15
<15
Product fineness %
8-12
8-12
8-12
8-12
8-12
Product moisture %
<1
<1
<1
<1
<1
Power of main motor Kw
200
200
280
315
400
Feeding ar temperature ℃
<450
<450
<450
<450
<450
Discharge air temperature ℃
80-95
80-95
80-95
80-95
80-95
Air discharging volume M3/H
~40000
~45000
65000
80000
100000
Weight T
45
52
75
96
100
Our Certification
Our Company
Packing&Shipping
FAQ
Q: Are your vertical roller mill can procee the slag and other hard materials?
A: Our grinding parts of the vertical roller mill are made by hard materials, so it can be used in slag, cement and other hard materials grinding.
Q: What the fineness range of the vertical roller mill?
A: It can be adjusted between 300 mesh to 4000 mesh.
Q: Are you a manufacturer or middleman?
A: Our Shanghai Clirik is a professional vertical roller mill manufacturer.
